Long shaft 65qv vertical A05 mud pump, mud pump, vertical pump

Long shaft 65qv vertical a05 sump slurry pump, slurry sump pump, vertical pump The Depump vertical sump pump excellence is embodied in the range of vertical Sump Pumps. Use a variety of speed and various modifications way, makes the pump in the best condition operation, long service life, high opera

Featured Products

Long shaft 65qv vertical a05 sump slurry pump, slurry sump pump, vertical pumpLong Shaft 65qv Vertical A05 Sump Slurry Pump, Slurry Sump Pump, Vertical Pump


The Depump vertical sump pump excellence is embodied in the range of vertical Sump Pumps. Use a variety of speed and various modifications way, makes the pump in the best condition operation, long service life, high operating efficiency and can meet many kinds of poor transport conditions. It's widely used in the  metallurgy, mining, coal, power, building materials, environmental protection and other departments.

Product Description

Long Shaft 65qv Vertical A05 Sump Slurry Pump, Slurry Sump Pump, Vertical Pump
Long Shaft 65qv Vertical A05 Sump Slurry Pump, Slurry Sump Pump, Vertical Pump


Feature

CANTILEVERED SHAFT
The standard MSP pumps feature a cantilevered shaft which is up to 2400mm long. The cantilevered shaft means that there is no shaft sealing requirement and the drive end bearings do not come into contact with any pumped product. This reduces the risk of bearing failure and extends the wear life of the pumps.

HEAVY DUTY WET END
Wet end components are manufactured from high quality 27% chrome white iron or rubber coated steel for exceptional wear resistance and service life with minimal corrosion. The heavy duty design can pump high density and abraisive slurries and the large passages of the impeller allows the transfer of large particles without blockages in a wide range of mining, processing and heavy industrial applications. Wet end stub shaft options are available to suit severe duty applications.

COLUMN AND DISCHARGE PIPES
Column and discharge pipes are available in a range of materials to suit the requirements of operators. Standard options include mild steel and rubber lined mild steel. Composite options are available.

VERSATILE DRIVE OPTIONS
MSP pumps can be directly driven using electric motors or belt driven with either set speed or variable speed operation.

REMOVABLE STRAINERS
MSP pumps feature rubber or cast iron upper strainers and cast iron lower strainers to prevent blockages. The strainers are easily removed for servicing or replacement.

"L" MODELS EXTENDED SHAFT
The extended shaft "L" model features column bearings and shaft seal which further extends the pumping depth and enables the transfer of slurries from deeper sumps and pits.


Pump Details
Long Shaft 65qv Vertical A05 Sump Slurry Pump, Slurry Sump Pump, Vertical Pump


Material

DescriptionStandard MaterialMaterial Options
Shaft4140 Mild SteelAvailable on Request
Bearing HousingCast Iron
ColumnMild Steel
Upper StrainerRubberCast Iron
Lower StrainerCast Iron
Back Liner27% Chrome White Iron
Pump Casing27% Chrome White IronRubber Lined White Iron
Impeller27% Chrome White IronRubber
Discharge PipeMild SteelRubber Lined Mild Steel/ Composite
Adaptor PlateMild Steel



Performance Curve

Long Shaft 65qv Vertical A05 Sump Slurry Pump, Slurry Sump Pump, Vertical Pump


Performance Table
Model

Max. Power

(kw)

MaterialFlow(L/S)Head(m)Speed(r/min)Max. efficiencyNo. of Vanes

Impeller Diameter

(mm)

Weight(kg)
                                                                MSP
40PV15Cr275-124-281000-2200405188285
65QV306-245-31700-1500585280430
100RV7515-805-35500-1200565370860
150SV11030-1308-40500-10005254501700
                                                               MSPR
40PV15Rubber5-114-261000-2200405188280
65QV306-295-30700-1500515280420
100RV7518-805-35600-1200625370840
150SV11030-1308-40500-10005254501700

 *****More pump models please contact us*****
Long Shaft 65qv Vertical A05 Sump Slurry Pump, Slurry Sump Pump, Vertical Pump

Application

The MSP Heavy Duty Sump Pumps are capable of providing reliable and efficient performance for the transfer of abraisive and high density slurries from sumps, pits and tanks in a wide range of mining, processing and heavy industrial applications.


Long Shaft 65qv Vertical A05 Sump Slurry Pump, Slurry Sump Pump, Vertical Pump
Long Shaft 65qv Vertical A05 Sump Slurry Pump, Slurry Sump Pump, Vertical Pump
Long Shaft 65qv Vertical A05 Sump Slurry Pump, Slurry Sump Pump, Vertical Pump

Long Shaft 65qv Vertical A05 Sump Slurry Pump, Slurry Sump Pump, Vertical PumpLong Shaft 65qv Vertical A05 Sump Slurry Pump, Slurry Sump Pump, Vertical Pump
FAQ

A: What kind of company you are?
Q: Shijiazhuang Depon Pump Company is professional manufacturer in pumps. After accumulation and development of many years, we have formed a complete system of pump design, selection, application, manufacture, marketing and maintenance. We have passed CE, SGS certificate. Our customers are at home and abroad. Hope to coorperate with the worldwide friends.

Q: What's your MOQ?
A: Trial sample order is OK.

Q: What are your payment terms?
A: T/T, L/C, D/P, D/A or as customer required

Q: How about the warranty?
A: One year warranty for pumps, it depends on other pump working condition details.

Q: What is the delivery time?
A: 7-30 days according to customer quantities.

Q: Can you do OEM brand?
A: Yes, Welcome.

Q: What information should I offer to get pump solution?
1, Head:     m
2, Flow:    m3/h
3, Max Solid size:    mm
4, Particle shape (smooth or sharp):
5, Medium pH level:
6,Specific Gravity of the Medium:
7, Temperature:
8, Drive type:
9. Power supply: Electric or Dlesel
10, Voltage and Frequency of the Motor:



Welcome inquiry!
